型号 |
安装尺寸 |
轴伸尺寸 |
外形尺寸 | |||||||||||
H0 |
B0
a2 |
A0 |
d0 |
d |
b
c |
L2 |
M1 |
B |
q
L1 |
H
g1 |
W1
f4 |
h1
A |
W2 | |
TKA35 |
100 |
60
35 |
117 |
M10×20 |
30H7 |
8
33.3 |
105 |
M10×25 |
100 |
71
142 |
164
120 |
60
2.5 |
8.5
147 |
63 |
TKA48 |
112 |
70
40 |
140 |
M10×20 |
35H7 |
10
38.3 |
130 |
M12×25 |
110 |
75
166 |
185
160 |
75
3 |
7.2
175 |
78 |
TKA58 |
132 |
88
47 |
152 |
M12×25 |
40H7 |
12
43.3 |
142 |
M16×40 |
122 |
96
173 |
215
160 |
83
3 |
13.1
207 |
86 |
TKA68 |
140 |
88
42 |
152 |
M12×25 |
40H7 |
12
43.3 |
156 |
M16×40 |
130 |
94
179 |
226
160 |
90
3.5 |
20
207 |
93 |
TKA78 |
180 |
102
48 |
170 |
M16×32 |
50H7 |
14
53.8 |
183 |
M16×40 |
154 |
109
202 |
286
200 |
105
4 |
31.3
225 |
108 |
TKA88 |
212 |
118
65 |
225 |
M16×32 |
60H7 |
18
64.4 |
210 |
M20×50 |
170 |
132
257 |
338
250 |
120
4 |
25.9
300 |
123 |
TKA98 |
265 |
160
83 |
248 |
M20×36 |
70H7 |
20
74.9 |
270 |
M20×50 |
226 |
158
277 |
414
300 |
150
4 |
32.3
328 |
153 |
TKA108 |
315 |
190
100 |
290 |
M24×44 |
90H7 |
25
95.4 |
310 |
M24×60 |
266 |
199
354 |
500
350 |
175
2.5 |
52
400 |
178 |
TKA128 |
同TKAB128 | |||||||||||||
TKA158 |
同TKAB158 |
型号 |
安装尺寸 |
外形尺寸 | |||||||||
L5 |
β |
C8 |
R |
p |
l |
H0 |
d1 |
L4+0 -0.3 |
a4 |
d2+0.25 +0.1 | |
TKAT38 |
31 |
60° |
10 |
22.5 |
140 |
20 |
100 |
10.4±0.1 |
36 |
23.5 |
26 |
TKAT48 |
31 |
55° |
12 |
22.5 |
160 |
20 |
112 |
10.4±0.1 |
36 |
30 |
26 |
TKAT58 |
54 |
55° |
13 |
29 |
192 |
18 |
132 |
16.4±0.08 |
60 |
40 |
40 |
TKAT68 |
54 |
55° |
13 |
29 |
200 |
25 |
140 |
16.4±0.08 |
60 |
45 |
40 |
TKAT78 |
54 |
60° |
14 |
29 |
250 |
25 |
180 |
16.4±0.08 |
60 |
52.5 |
40 |
TKAT88 |
72 |
60° |
16 |
41 |
300 |
30 |
212 |
25±0.08 |
80 |
60 |
60 |
TKAT98 |
92 |
50° |
17 |
41 |
350 |
40 |
265 |
25±0.08 |
100 |
70 |
60 |
TKAT108 |
92 |
55° |
20 |
41 |
450 |
45 |
315 |
25±0.08 |
100 |
74 |
60 |
TKAT128 |
110 |
65° |
45 |
70 |
550 |
7 |
375 |
40±0.08 |
126 |
60 |
- |
TKAT158 |
110 |
75° |
45 |
70 |
700 |
2 |
450 |
40±0.08 |
126 |
50 |
- |
